Plug 8P Serial Unshielded ATRP8P8C-XAX-004

Introducing the Plug 8P Serial Unshielded ATRP8P8C-XAX-004 - the superhero of all plugs! This little guy is here to save the day, connecting your devices faster than a speeding bullet. With its unshielded design, it fearlessly battles against electromagnetic interference, ensuring a seamless connection every time. It's like having a personal bodyguard for your data! Plus, its 8P8C-XAX-004 features make it the James Bond of plugs - sleek, mysterious, and ready to take on any mission. So, say goodbye to tangled wires and hello to a plug that's faster than a cheetah on caffeine. Get your hands on the Plug 8P Serial Unshielded ATRP8P8C-XAX-004 and experience the superhero power for yourself!

PLUG 8P8C FOR Flat Cable,Short type  ATRP8P8C-XAX-004 Specification

1.Electrial Test:
 A:250V AC max at 2 Amps
 B:Dielectric with standing 500volts AC
 C:Insulation Resistance:500 mega Ω
 D:Termination Resistance:35 mega Ω
2.Mechanical:
 A:Cable to Plug tensile strength
   20LBs(89N)min
 B:Durability:1000 mating cycles

Plug 8P8C Serial shielded ATRP8P8C-XAX-004 Dimensions:
