mini display port plug

"The Ultimate Guide to Mini Display Port Plugs: Everything You Need to Know Before Making a Purchase"

$500

≥1000
Piece/Pieces

Payment Type:

L/C,Paypal,T/T

Incoterm:

FOB,CIF,EXW

1000

Min. Order:

1000 Piece/Pieces

Transportation:

Ocean,Air

Port:

shenzhen

Contact Now

 Chat Now

Product Description

Product Attributes
Supply Ability & Additional Information
Packaging & Delivery
Company Overview
Company Photos
Production Certification

< >

Overview

Product Attributes

Model No.: MDP-MXX01

Brand: antenk

Place Of Origin: China

Application: Pcb

Gender: Female

Contacts: 20p

Supply Ability & Additional Information

Packaging: reel & tape,bag

Productivity: 100000/month

Transportation: Ocean,Air

Place of Origin: china

Supply Ability: 100000/month

Certificate: iso9001

HS Code: 8536909000

Port: shenzhen

Payment Type: L/C,Paypal,T/T

Incoterm: FOB,CIF,EXW

Packaging & Delivery

Selling Units:: Piece/Pieces

Package Type:: reel & tape,bag

Introducing our Mini DisplayPort Plug, the perfect accessory for seamless connectivity between your devices! This compact and versatile plug allows you to effortlessly connect your laptop, tablet, or desktop to a larger display, such as a monitor or projector, with stunning clarity and resolution. With its sleek design and durable build, this plug ensures a secure and reliable connection every time. Enjoy the convenience of transmitting high-quality audio and video signals, making it ideal for presentations, gaming, or simply enhancing your multimedia experience. Upgrade your connectivity options today with our Mini DisplayPort Plug!

Mini Display Port receptacle (straddle 1.6mm straight legs)

Notes:
Material
Body: LCP.UL94V-0 Rated; Color: White Insertion
(Molding):LCP,UL94V-0 Rated;
Shell: Brass.
Plating: Nickel Plating
Contact: Phosphor Bronze
Plating: Tin Plating On Solder tail,Gold Plating Over Nickel 0n Contact Area;
Electrical Specification
Operation Voltage: 30 VAC max.
Current Rating:0.5 Ampere Per contact.
Contact Resistance :30 mΩ Max.
Insulation Resistance :100 MΩ Min.
Dielectric Withstanding Voltage: 500v AC Min.
Mechanical
Insertion Force :4.5Kg/f max.
Withdrawal Force:1.0~4.0Kg/f.
Durability:10,000 Cycles
Environmental
Operating Temperature:-40°C to +85°C
