13.14mm Receptacle Stack Angle DIP USB

Introducing the game-changing 13.14mm Receptacle Stack Angle DIP USB, designed exclusively for professionals seeking unparalleled connectivity solutions. This cutting-edge product boasts a compact and sleek design, ensuring seamless integration into any professional setup. With its stack angle feature, it allows for effortless stacking of multiple USB connections, optimizing space utilization and enhancing productivity. The 13.14mm receptacle ensures secure and reliable connections, eliminating any worries of data loss or interruptions. Whether you're a tech-savvy individual or a business looking to streamline your operations, this DIP USB is your ultimate solution. Upgrade your professional experience today!

13.14mm Receptacle Stack Angle DIP USB

Specifications：

Current Rating:1.5A Max

Contact Resistance:30MΩ Max

Dielectric Withstanding Voltage:500V AC at Sea Levol

Insulation Resistance:1000MΩ Min

Housing: LCP UL94V-0

Contact:
Copper Alloy T=0.25mm Piated Gold in Mating Area;
Tin On Solder Talls
Shell:Iron T=0.30mm Nickel/Plating

2D Drawing:
