2.54mm Dual-in-line Socket Straight DIP(H=3 L=20.9)

Introducing the high-quality 2.54mm Dual-in-line Socket Straight DIP (H=3 L=20.9) - an essential component for your electronic projects. This socket is meticulously designed to ensure secure and reliable connections. With a pitch of 2.54mm, it offers compatibility with a wide range of DIP ICs. The straight design allows for easy installation on your PCB, saving you valuable time and effort. Crafted with precision, this socket guarantees optimal electrical conductivity and durability. Its compact size (H=3 L=20.9) ensures seamless integration into your circuitry. Upgrade your electronic assemblies with this reliable and versatile DIP socket today!

2.54mm Dual-in-line Socket StraightDIP (H=3 L=20.9) Square Pin connector

Specifications:

Current Rating: 1.0Amp

Contact Resistance: 10MΩ  max

Dielectric Strength: Min 1000V RMS

Mechanical Life: Min 100 cycles

Operating Temperature:-40°C to +105°C

Sleeve: Brass CuZn36Pb3(C36000)

Contact Clip(4 finger): BeCu(C17200)

Contact Plating: Au or Sn Over Ni

Insulator Material: PPS+30%GF UL 94V-0

06p~16P Insulators without center bar

36p~52P  Insulators with center two bar

64P  Insulators with center three  bar
