1.27mm Box Header 180° H=5.70

Introducing our latest innovation, the 1.27mm Box Header 180° H=5.70! This cutting-edge connector is designed to revolutionize your electronic projects. With a compact size of just 1.27mm, it offers exceptional space-saving capabilities while ensuring a secure and reliable connection. The 180° angle allows for effortless installation, even in tight spaces. Its robust construction guarantees durability and longevity, making it perfect for various applications. Whether you're working on PCBs, robotics, or any other electronic endeavor, our 1.27mm Box Header 180° H=5.70 is your ultimate solution. Elevate your projects with this exceptional connector today!

Shenzhen Antenk Electronics Co., Ltd. promoted a 1.27mm pitch Box Header 180°, plastic height H=5.70mm connector.
In order to design a connector that meets the functional requirements, material selection is very important, and the basis of material selection is to understand the performance of the material. The following is an explanation of the terminology of the metal properties of the connector. I hope to help you.
1. Chemical composition
The metal material used in the connector is generally an alloy material, and a single metal material is rarely used. As the name implies, the alloy has a plurality of metal-synthesized substances, indicating that it has various chemical elements, such as:
  Phosphor bronze: It consists of copper Cu, tin Sn, phosphorus P, iron Fe, lead Pb, zinc Zn, etc. The main component is copper.
Brass: It consists of copper Cu, iron Fe, lead Pb, zinc Zn, etc. The main component is copper.

Stainless steel: from iron Fe, chromium Cr, nickel Ni, carbon C, silicon Si, manganese Mn, phosphorus P, sulfur S, aluminum Al, cobalt Co, the main component is iron.

product information:

1.No.of Contacts: 06P 08P 10P 14P  16P 20P 24P 26P  30P  32P 34P 40P 44P  50P  60P 64P 80P 100P

2.Connector Type: Double row.

3.Plastic High:H=5.70mm.

4.Packing:Tray / Bag / Tube / Tube+CAP / Tape&Reel / Tape&Reel+CAP.

   SPECIFICATION
Current Rating:                       1Amp
Insulation Resistance:            1000MΩ  min
Contact Resistance:               20MΩ  max
 Withstand Voltage:                500V AC/DC
Operating Temperature:        -40°C  to  +105°C
Contact Material:                    Brass
Contact Plating:                      Au or Sn Over Ni
Insulator Material:              PA6T+30%GF UL 94V-0
