4P RJ45 SMT Jack Connector

"Enhancing Connectivity and Reliability: An In-depth Analysis of 4P RJ45 SMT Jack Connector for Professionals"

  • $500
    ≥1000
    Piece/Pieces
Payment Type:
L/C,T/T,Paypal
Incoterm:
FOB,CFR,CIF,EXW
1000
Min. Order:
1000 Piece/Pieces
Transportation:
Ocean,Air,Express
Port:
Shenzhen
Share:
Chat Now
  • Product Description
Overview
Product Attributes

Model No.ATRJ5826B-4P4C-X-A-X

BrandAntenk

Place Of OriginChina

Interface TypeD-SUB(VGA)

HousingPlastic

PinBrass

PolesOther

ApplicationOther

CertificationCE

GenderMale

MaterialCopper

Support Card NumberOther

Operating FrequencyHigh Frequency

ClassificationWired Broadband Connection

Inner PackingTray

Supply Ability & Additional Information

Packagingbag packing,Tube packing, reel packing

Productivity 2000K/Month

TransportationOcean,Air,Express

Place of OriginChina

Supply Ability2000K/Month

CertificateISO 9001-2015

HS Code8536909000

PortShenzhen

Payment TypeL/C,T/T,Paypal

IncotermFOB,CFR,CIF,EXW

Packaging & Delivery
Selling Units:
Piece/Pieces
Package Type:
bag packing,Tube packing, reel packing

Introducing the 4P RJ45 SMT Jack Connector, the ultimate gadget for all your networking needs! This little powerhouse will have you saying goodbye to slow internet speeds and hello to lightning-fast connections. With its sleek design and easy installation, you'll be up and running in no time. But wait, there's more! This connector is so durable, it can withstand even the clumsiest of fingers (we're looking at you, butterfingers). It's like a ninja warrior of connectivity, silently working its magic behind the scenes. So why settle for mediocre when you can have the 4P RJ45 SMT Jack Connector? Upgrade your network game and prepare to be blown away!

RJ45 RJ45 SIDE ENTRY SMT JACK 4P


Specifications:

MATERIAL:
   1.HOUSING MATERIAL:GLASS FILLED POLYESTER UL94V-0.
   2.CONTACT MATERIAL:PHOSPHOR BRONZE t=0.35mm
   3.PLATING:SELECTING GOLD PLATING
1u"~50u"OVER NICKEL IN CONTACT AREA.150u"TIN  PLATING
OVER NICKEL IN SOLDER AREA.
   4.SHIELD :0.25mm THICKNESS COPPER ALLY WITH NICKEL .PLATEL
ELECTRICAL:
   1.VOLTAGE PATING:125 VAC RMS.
   2.CURRENT PATING:1.5 AMP
   3.CONTACT RESISTANCE:35 MILLIOHMS MAX
   4.INSULATION   RESISTANCE:1000 MEGOHMS MIN @ 500V DC.
   5.DIELECTRIC WITHSTANDING RESISTANCE: 1000V AC RMS 60Hz.1MIN
MECHANICAL:
   1.DURRABILITY:750 CYCLES MIN
   2.PCB RETENTION PRE-SOLDER :10LB MIN
ENVIRONMENTAL:
   1.STORAGE:-40℃ TO +85℃ .
   2.OPERATION:-40℃ TO +85℃ .
   3.IR REFLOW SOLDERING TEMPERRATURE:255~265℃(5~10  SECONDS)MATES WITH Modular Plug CONFORMING TO FCC PART 68 SUBPART F.

ATRJ5826B-4P4C-X-A-X
