2.5mm Pitch Male Terminal

The 2.5mm Pitch Male Terminal is a high-quality electrical connector designed to provide secure and reliable connections in various applications. With a pitch of 2.5mm, this terminal offers precise and accurate mating with compatible female connectors. It features a durable construction, ensuring long-lasting performance even in demanding environments. This male terminal is easy to install and provides excellent conductivity for efficient electrical transmission. It is suitable for use in industries such as automotive, electronics, and telecommunications. Whether you need to replace a damaged terminal or create new connections, the 2.5mm Pitch Male Terminal is a dependable choice.

AT2508V-M 2.5mm Pitch Male Terminal

Manufacturer :ANTENK ELECTRONICS., CO. LTD.

High quality, competitive price, fast delivery, quick reply. UL, Rohs, Reach passed.

Enterprise slogan: a group of people, one heart, work together, will win
Corporate Mission: Connecting the World and Connecting the Future
Corporate Vision: Become the First Brand of Famous Connectors
Values: Diligence, Gratitude and Honesty

Product name:2.5mm Pitch Male Dual row Housing Connector

Specifications:
Part No.:AT2508V-M
Voltage rating:250V AC/DC
Current rating:3A AC/DC
Withstanding voltage:1000V AC/minute
Temperature range: -25℃~+85℃
Insulation resistance:≥1000MΩ
Contact resistance: ≤10mΩ
After environmental testing :≤20mΩ
Material:Phosphor Bronze
Finish:10~15u" Ni;60~80u"Sn
Wire Range:AWG#22-26
Q'ty/Reel:7000Pcs
